The main features:
Suitable to middle or long distance transportation on highway road
Pattern designed with super anti-sideslip and anti-wet performance
Supplies high fuel effcoency with low rolling resistance,low noise emission and anti-irregular-wear performance
Super strong bead construction gives excellent high speed endurance ability
| SIZE | PR | LOAD INDEX | SPEED SYMBOL | PATTERN DEPTH (mm) | STANDARD RIM | PERMITTED RIM | MAX LOAD （Kg） | PRESSURE (Kpa) | NEW TIRE INFLATED DIMENSION (mm) | ||
| S | D | OD | SW | ||||||||
| ±1.0% | ±3.5% | ||||||||||
| 11R22.5 | 16 | 146/143 | M | 15.50 | 8.25 | 7.5 | 3000 | 2725 | 830 | 1054 | 279 |
| 11R24.5 | 16 | 149/146 | M | 14.00 | 8.25 | 3250 | 3000 | 830/830 | 1104 | 279 | |
| 285/75R24.5 | 16 | 147/144 | M | 14.50 | 8.25 | 3075 | 2800 | 830/830 | 1050 | 283 | |
| 295/75R22.5 | 16 | 146/143 | M | 14.50 | 9 | 3000 | 2725 | 830/830 | 1014 | 298 | |
| 225/75R17.5 | 16 | 129/127 | L | 13.00 | 6.75 | 1850 | 1750 | 725/725 | 784 | 228 | |
| 255/70R22.5 | 16 | 140/137 | L | 13.00 | 7.5 | 2500 | 2300 | 800/800 | 930 | 255 | |
| 315/80R22.5 | 18 | 154/151 | M | 17.00 | 9 | 9.75 | 4000 | 3650 | 850 | 1076 | 312 |
